When you select the Base Flange feature, a sketch opens on the plane. on the Sheet Metal toolbar, or click Insert > Sheet Metal > Base Flange. The controls on the Base Flange PropertyManager update according to your sketch.

.

Keeping this in consideration, what is a base flange?

A base flange is the first feature in a new sheet metal part. When you add a base flange feature to a SOLIDWORKS part, the part is marked as a sheet metal part. Bends are added wherever appropriate, and sheet metal specific features are added to the FeatureManager design tree.

Beside above, how do I use sheet metal in Solidworks? To convert a solid part to a sheet metal part:

1. Create the solid part.
2. Click Convert to Sheet Metal (Sheet Metal toolbar) or Insert > Sheet Metal > Convert To Sheet Metal .
3. In the PropertyManager, under Sheet Metal Gauges, set options if you want to use a gauge table:
4. Under Sheet Metal Parameters:

Considering this, how do I use the edge flange in Solidworks?

Adding Edge Flanges

1. In an open sheet metal part, click Edge Flange. (Sheet Metal toolbar) or Insert > Sheet Metal > Edge Flange.
2. In the graphics area, select one or more edges for Edge . There are specific requirements for adding edge flanges to curved edges. See Edge Flanges .
3. Set options in the Edge-Flange PropertyManager and click .

What does thin feature do in Solidworks?

If an open contour is used, then these features become thin features. The 'Thin Feature' section in the property manager can specify which side of the open contour for the material thickness to reside and how thick the thin feature should be.

Related Question Answers

How do you run in Solidworks?

Sketch a line on the face of a sheet metal part where you want to create the jog. Alternatively, you can select the jog feature before you create a sketch (but after you select a plane). When you select the jog feature, a sketch opens on the plane. on the Sheet Metal toolbar, or click Insert > Sheet Metal > Jog.

How do you cut sheet metal in Solidworks?

To cut across sheet metal bends:

1. In an existing sheet metal part, click Unfold. or Insert > Sheet Metal > Unfold.
2. In the graphics area:
3. Click .
4. Sketch a closed profile across the flattened bend, and extrude the cut Through All.
5. To restore the part to the bent state, click Fold.
6. In the graphics area:
7. Click .

Where is the Sheet Metal toolbar in Solidworks?

To display SOLIDWORKS toolbars:

1. Right-click in the window border and select or clear a toolbar name.
2. Click Tools > Customize. On the Toolbars tab, select the toolbars to display.

How do you make a tab in Solidworks?

To create a tab and slot:

1. In a part, click Tab and Slot (Sheet Metal toolbar) or Insert > Sheet Metal > Tab and Slot.
2. In the PropertyManager, specify options.
3. In the graphics area, select an edge for the tabs and a corresponding face for the slots.
4. Click .

How do I add a surface toolbar in Solidworks?

SOLIDWORKS Toolbars

1. Right-click in the window border and select or clear a toolbar name.
2. Click Tools > Customize. On the Toolbars tab, select the toolbars to display.

What is a flange in sheet metal?

Sheet metal flange features consist of a face and bend connected to an existing face along a straight edge. Flange features are added by selecting one or more edges and specifying a set of options that determine the size and position of the material added.

How do you bend in SolidWorks?

To create a sketched bend feature:

1. Sketch a line on a planar face of the sheet metal part.
2. Click Sketched Bend.
3. In the graphics area, select a face that does not move as a result of the bend for Fixed Face .
4. Click a Bend position of Bend Centerline , Material Inside , Material Outside , or Bend Outside .

How do you flange sheet metal?

A flange feature consists of a face and bend connected to an existing face along a straight edge. To add a flange feature, you select one or more edge, and specify a set of options that determine the size and position of the material added.

How do you sketch bend in SolidWorks?

To create a sketched bend feature:

1. Sketch a line on a planar face of the sheet metal part.
2. Click Sketched Bend.
3. In the graphics area, select a face that does not move as a result of the bend for Fixed Face .
4. Click a Bend position of Bend Centerline , Material Inside , Material Outside , or Bend Outside .

How do you add a sheet metal tab in SolidWorks?

To create a tab feature in a sheet metal part:

1. Create a sketch on a plane or planar face that meets the sheet metal tab requirements.
2. Click Base Flange/Tab. on the Sheet Metal toolbar, or click Insert > Sheet Metal > Base Flange . The tab is added to the sheet metal part.

What is K factor in sheet metal?

The K-Factor in sheet metal working is the ratio of the neutral axis to the material thickness. When metal is bent the top section is going to undergo compression and the bottom section will be stretched. The K-Factor is the ratio of the Neutral Axis' Offset (t) and the Material Thickness (MT).

How do you make sheet metal parts in Solidworks?

To create a sheet metal part from the flattened state:

1. Open a new part.
2. Create a sketch as shown. You do not have to dimension the part.
3. Create a Base-Flange by clicking Base-Flange/Tab.
4. To bend the sheet metal part, sketch lines on the part as shown.
5. Bend the part by clicking Sketched Bend.
