Step 1: Download X-CTU Software. The X-CTU software is free to download and provides a simple interface to configure and update your XBee transceivers. … Step 2: Put together your XBee breakout board. … Step 3: Configure 1st XBee as a coordinator. … Step 4: Configure 2nd XBee as Router. … Step 5: Test the configuration.

How do I configure XBee?

1. XBee connection with USB adapter. Place the XBee module on XBee USB adapter:
2. Download and Install XCTU software 6.1. …
3. Now configure the first radio as COORDINATOR. …
4. Now click on the second radio and configure this as ROUTER. …
5. Communication between Coordinator and Router. …
6. Check the Output.

How do I know if XBee is working?

1. Check cables. The USB cables should be firmly and fully attached to both the computer and the XBee development board. …
2. Check that the XBee module is fully seated in the XBee Grove Development Board. …
3. Check the XBee module orientation. …
4. Check that the XBee modules are in the same network. …
5. Restore default settings.

How do I connect XBee to Arduino?

Set Up Your Circuits Connect the ground and 3.3V from the Arduino to the ground and power rails of your breadboard. Connect the power and ground rails of the breadboard to the 3.3V and GND pins on your Explorer module. Next, connect the XBee Explorer pin OUT to Arduino pin 2 (RX), and XBee pin IN to Arduino pin 3 (TX).

Is XBee a WiFi?

As a member of the XBee family, the XBee WiFi combines hardware with software for a complete modular solution. XBee WiFi modules are designed to communicate with access points in existing 802.11 infrastructures. Developers can use AT and API commands for advanced configuration options.

How do I connect XBee modules?

1. Connect two XBee modules to your computer using the USB cables. …
2. Launch XCTU.
3. Click the Configuration working modes button .
4. Click the Discover radio modules button .
5. In the Discover radio devices dialog, select the serial ports where you want to look for XBee modules, and click Next.

How do I connect XBee to my computer?

1. Plug your XBee into your XBee Explorer, and plug the Explorer into your computer. …
2. Open XCTU. …
3. Hit Test/Query to make sure you can communicate with your XBee WiFi. …
4. Click over to the “Modem Configuration” tab. …
5. Select “Active Scan” near the top of the scrolling window.

How do I use XBee USB adapter?

Simply plug the XBee 3 USB Adapter into the USB port of a laptop or PC for instant access to an Digi XBee network and its connected devices. This compact, USB-powered wireless adapter enables local network configuration, diagnostics or device monitoring. The XBee 3 USB Adapter can be programmed with Zigbee, 802.15.

How do I program XBee pro?

1. Step 1: Download X-CTU Software. The X-CTU software is free to download and provides a simple interface to configure and update your XBee transceivers. …
2. Step 2: Put together your XBee breakout board. …
3. Step 3: Configure 1st XBee as a coordinator. …
4. Step 4: Configure 2nd XBee as Router. …
5. Step 5: Test the configuration.

What is the use of XBee module?

XBee – According to Digi “XBee modules are embedded solutions providing wireless end-point connectivity to devices. These modules use the IEEE 802.15. 4 networking protocol for fast point-to-multipoint or peer-to-peer networking.

Article first time published on

What is the difference between Zigbee and XBee?

XBee is a family of radio modules and is a registered trademark of Digi International. Zigbee is a wireless communications protocol and a registered trademark of the Zigbee Alliance. Many people confuse these two names because both are involved in radio networking and have “Bee” in their branding.

What is XBee Arduino?

Overview. The Xbee shield allows an Arduino board to communicate wirelessly using Zigbee. It is based on the Xbee module from MaxStream. The module can communicate up to 100 feet indoors or 300 feet outdoors (with line-of-sight). … The shields breaks out each of the Xbee’s pins to a through-hole solder pad.

What is XCTU?

XCTU is a free multi-platform application designed to enable developers to interact with Digi RF modules through a simple-to-use graphical interface. It includes new tools that make it easy to set-up, configure and test XBee® RF modules.

How does Zigbee transmit and receive data?

In order to transmit or receive data on Xbee modules, they need to be properly configured on the same network. According to the Zigbee protocol one device needs to be in coordinator mode and the rest can be router or end devices. In this case, one device is coordinator and other is router.

What is a Zigbee module?

Zigbee is a low-cost, low-power, wireless mesh network standard targeted at battery-powered devices in wireless control and monitoring applications. Zigbee delivers low-latency communication. Zigbee chips are typically integrated with radios and with microcontrollers.

How do I connect my XBee to my laptop?

To connect XBee module with the laptop, a USB to serial converter or specifically designed explorer board is used. Just hook up the XBee module to the Explorer board and plug it with the laptop using USB cable.

What is XBee transmitter?

XBee is an RF module mainly used as a radio communication transceiver and receiver. It is mesh communication protocols, also XBee supports peer-to-peer as well as point to multi-point network communications wirelessly with the speed of 250 kbits/s, to operate XBee you need a transmitter and a receiver.

How do I communicate with XBee?

XBee devices communicate with each other over the air, sending and receiving wireless messages. The devices only transfer those wireless messages; they cannot manage the received or sent data. However, they can communicate with intelligent devices via the serial interface.

Why is XBee so expensive?

Zigbee devices are typically more expensive because they have to comply with various specifications from the Zigbee Alliance – giving rise to various subtle benefits compared to non-Zigbee devices.

Is XBee a Bluetooth?

Your Digi XBee 3 radio module now has Bluetooth activated and will allow secure connections from the XBee Mobile application. You can leave the XBIB evaluation board connected to the computer for power, or change to a portable USB battery power supply to go fully wireless.

How do I transfer data from Arduino to XBee?

For this, connect one end of the button to D5 of Arduino and the other end of the button to GND. Connect VCC (pin 1) of XBee module to 3.3V of Arduino Nano and GND (pin 10) of XBee to GND of Arduino Nano. These two connections make up for powering the transmitting side XBee module.

Why ZigBee is better than WiFi?

ZigBee’s data transfer speed is lower than WiFi’s, too. It’s maximum speed is just 250kbps, much lower than the lowest speed WiFi offers. ZigBee’s best quality is its low power-consumption rate and battery life.

Which is better ZigBee or Bluetooth?

S.NOBluetoothZigbee5.Bluetooth requires low bandwidth.While zigbee also requires low bandwidth but greater than Bluetooth’s bandwidth most of time.

What's better ZigBee or Z-Wave?

ZigBee operates at 2.4 GHz compared to the 908 MHz of Z-Wave. The higher frequency allows ZigBee to transmit more data but reduces the range of the signal. … A Z-Wave signal between two nodes can travel up to 330 feet in an outdoor, unobstructed setting.

How do I connect XBee to Arduino Nano?

Connect VCC (pin 1) of XBee module to 3.3V of Arduino Nano and GND (pin 10) of XBee to GND of Arduino Nano. These two connections make up for powering the transmitting side XBee module. Connect Dout (pin 2) to D2 of Arduino Nano and Din (pin 3) to D3 of Arduino Nano.

How do I use Arduino WiFi module?

1. connect the red wire to VIN(3.3V) to the +3.3V power from the microcontroller.
2. connect the black wire to the ground.
3. connect the green wire to the TX of the Wifi module and microcontroller.
4. connect the yellow wite to the RX of the wifi module and microcontroller.

How do I connect Bluetooth to Arduino?

1. Download the Application form here or here.
2. Pair your device with HC 05/06 Bluetooth module1) Turn ON HC 05/06 Bluetooth module2) Scan for available device3) Pair to HC 05/06 by entering default password 1234 OR 0000.
3. Install LED application on your android device.
4. Open the Application.

How do I use XCTU terminal?

1. Click the Tools drop-down menu and select MicroPython Terminal. The terminal opens.
2. Click Open. If you have not already added devices to XCTU: …
3. Click OK. …
4. Press Ctrl+B to get the MicroPython version banner and prompt.

How do I download XCTU?

1. Go to
2. Click Download.
3. Under Download XCTU, click the Windows installer link.
4. Once the download is complete, run the executable file and follow the steps in the XCTU Setup Wizard.

Can ZigBee transfer file?

Currently, files can be transferred correctly in the range of wireless network except the base station occurs some problems which may cause network paralyzed. … Although ZigBee owns some defect such as low bandwidth and transmission rate, the file whose data amount is not large could correctly transfer in this network.

How does ZigBee send data?

You can send Zigbee data packets as either unicast or broadcast transmissions. Unicast transmissions route data from one source device to one destination device, whereas broadcast transmissions are sent to many or all devices in the network.
